What is high speed disperser

What is high speed disperser

The high-speed disperser is composed of a driven vertical shaft and a high shear disc blade. The blades rotate at speeds up to 5000 FPM and form a radial flow pattern in a fixed mixing container. The blade creates a vortex that pulls the contents of the container to the sharp edge of the blade.

Get A Quote

Professional Team

5 designers with the title of engineer or above, 2 full-time material engineers, 6 technicians, all of whom have worked in well-known domestic and foreign companies;

Strong strength

Yancheng has a production base with a total investment of 120 million yuan. The plant covers an area of 6,000 square meters, of which the total investment in equipment is about 35 million yuan.

Quality Assurance

Choose aerospace materials, low wear; excellent and reasonable design of internal structure and overall machine; precise processing equipment, standardized production process workshop, quality assurance.

After-sales guarantee

Rucca promises to respond within 2 hours when receiving the buyer's report for repairs, provide a solution within 24 hours, and offer free damaged parts in warranty period.

about us

We Have The Best Solutions for Your Business

Rucca is a famous producer and designer of wet grinding and dispersing equipment in China,product list:Inline Dispersing System,Full Series of Bead Mills,Basket Mill,Mixing machine such as High Speed Disperser,Dual Shafts Mixers,Triple Shafts Dissolver,High Shearing Homogenizer,Grinding Beads,and Whole Production Line.



Learn More

The working principle of high speed disperser

Under the high-speed rotation of the sawtooth circular dispersing disc blade, the material is violently turned up and down in the container, colliding and shearing with the blade, so that the aggregate is destroyed to achieve rapid dispersion, homogeneous mixing, and accelerated dissolution. The phase material is stirred, dissolved and dispersed at high speed to complete the process of solid-liquid dispersion, wetting, depolymerization and stabilization.

Speed adjustment of high speed disperser

The speed can be adjusted arbitrarily (electromagnetic speed regulation and frequency conversion speed regulation). The speed regulation range is 80-1250 rpm. The medium speed is used for stirring and dissolving, and the high speed is used for dispersing and homogenizing. The main motor is a speed regulating motor,

High Speed Disperser For Ink

High speed ink dispersing machine Through the high-speed operation of the dispersing disc, the material flows in a ring shape, creating a vortex, and descending to the bottom of the vortex in a spiral shape. Intense shear shock and friction are generated between particles. Achieve rapid dispersion, dissolution and uniform mixing. It can be widely used in the processing of paints, printing inks, coatings, colorants, cosmetics, pesticides and other fields.

High speed disperser | Stepless speed regulation

There are electromagnetic speed regulation, frequency conversion speed regulation (such as for water-based paint) and explosion-proof frequency conversion speed regulation (such as for oil-based paint) and other forms. The stepless speed regulation function can fully meet the different process requirements in each process, and different speeds can be selected according to different process stages. It is not suitable for materials that do not add additives to the powder and have high requirements on the integrity of the product package.

Frequently Asked Question

Do you have any question?

The tip speed is the speed at the outer tip or edge of the spinning disk. Typical tip speed for a disperser, measured in feet per minute, is calculated by multiplying the constant 3.14 by the diameter of the disk (in feet) by the rotations per minute of the disk) of the agitator shaft. The industry term for tip speed is peripheral speed.

The dispersing machine is divided into experimental dispersing machine and production dispersing machine; The speed of the experimental type is divided into many, the common ones are 8000r/min, 2800r/min; The speed of production type is the same, generally 1500r/min, and the speed of higher power is 960r/min.
